F2.0 Large Aperture
More Light Input for Clearer Night Vision
1/3 CMOS Sensor
4MP Progressive Scanning CMOS Sensor
Powerful ISP module
Realistic and Vivid Colors at Night
Pan & Tilt
The camera can rotate 310° horizontally and 115°vertically, providing all-round monitoring without blind spots, ensuring the safety of your family at all times.
5/2.4GHz Dual-Band WiFi, Stable & Reliable
The 5GHz WiFi saves you from long waits and brings you a smoother live view with a faster speed and stronger signals. And the 2.4GHz WiFi ensures the stability of remote transmission. Two options for a better connection.
4 MP HD Resolution
High-quality imaging with 4 MP resolution(2560X1440). Say goodbye to blurry pictures and videos and discover more details that cannot be seen in low-quality videos.
Stunning Color Night Vision
The upgraded high-power dual-core lights bring you bright images at night with vivid colors and rich details.
These lights can also be used as street lightning. Fearless of the dark night!
Two-Way Audio
With the built-in microphone and speaker, you can talk to your elderly parents, children, babysitters, pets, etc, wherever you are. You can also welcome guests or warn off intruders when you’re miles away.
Intelligent Protection
Human Detection
Built-in AI chip to accurately filter non-human movements and reduce invalid alarms.
Real-Time Alerts
When a moving object is detected, the device will immediately trigger an alarm and push the alarm information to the phone.
Human Tracking
When an intruder is detected, the device will automatically track the target and record the entire event as key evidence.
Activity Zone Setting
Set an activity zone to monitor only a specific area of interest and not the camera’s entire field of view. If someone enters the zone, the system will send a push notification to the phone and record clips.
Remote Access and Control
Stay connected to your family or business by simply tapping the app or client!
No need to worry about data loss
Cloud storage is safer and more reliable.
Encrypted data transmission
Our data transmission is fully encrypted.
Optional Storage Method
Simple and Fast Networking
Spec
✮F2.0 large aperture, more light intake, clearer night vision.
✮Dual core light panel, full-color night vision
✮Dual band WiFi, stable connection
✮ISP image processing technology, preserving true colors
✮4 MP Ultra HD
✮Human detection, real time alerts
| Sorts | Type | Parameters |
| System | Operating system | Linux |
| Online visitor | Supports 4 visitors at the same time | |
| APP | O-KAM Pro | |
| Collection | CPU | Ingenic |
| Memory | 512Mb | |
| Lens | 4mm | |
| Image sensor | 1/3 4MP progressive scan CMOS sensor | |
| Min. Illumination | 0.5Lux (color mode), 0.1Lux (b&w mode) | |
| Sensor performance | Support automatic white balance, automatic gain control and automatic backlight compensation | |
| Night vision | Black and white night vision, full-color night vision | |
| Viewing angle | Diagonal: 108° | |
| Video | Resolution | 2560×1920/15FPS, 4 MP |
| Night vision | Black and white night vision, full-color night vision | |
| Compression standard | H.264 main profile/Motion-JPEG/JPEG | |
| IR control | IR-CUT, soft photosensitive control | |
| Bit rate | 128～4096kbps | |
| Image adjustment | Brightness, contrast, OSD display | |
| Audio | Input | Built-in -38dB microphone |
| Output | Built-in 8Ω1W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard/Bit Rate | G711A | |
| Pan/Tilt | Rotation angle | Pan：310° Tilt：115° |
| Network | Network interface | 10Mbps/100Mbps |
| Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P | |
| Wireless network | IEEE802.11b/g/n | |
| Wireless frequency | 2.4G/5G | |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption | |
| Storage | External TF card | Supports T-Flash cards (up to 256GB) |
| Cloud storage | Support cloud storage, users can purchase according to their needs. | |
| Alarm | Alarm detection | Motion detection, human detection, human framing, person tracking, and area detection |
| Physical Indicators | Rated voltage | DC5V±12% |
| Power consumption | Rated: 2.9W (0.58A); Full function on: 6W (1.2A) | |
| Operating condition | Working temperature: -10～45℃, working humidity <90% | |
| Weight | N.W：233g G.W：386g | |
| Camera size | 81x81x132mm | |
| Packaging box size | 90x90x185mm | |
| Carton size | 470x470x395mm, 50PCS/Carton |
