AI Humanoid detection
When there is a humanoid movement in the monitoring area, the alarm message will be pushed to the mobile phone immediately to reduce false alarms caused by the passing of animals and mosquitoes
Smart playback
Select playback by date and time point, download, share, and quickly find important video files. Don’t miss any important videos, and solve problems on time.
Delimitation detection
Draw the warning area, if someone moves in the monitoring area immediately push the warning message to the mobile phone.
3MP HD
The maximum pixel is 2304x1296P and the picture quality is delicate and captures more wonderful details. Zoom-in is still clear and records beautiful moments.
Infrared night vision, fine picture quality
Dual filter automatic switching, four lights night vision, the illumination distance is 10-15 meters, and the night is still clearly visible
Remote monitoring and multi-terminal
viewingSupports real-time viewing on various terminals, mobile phones, and PCs
Two-way talk
It supports two-way talk, a built-in high-power speaker, and a high-sensitivity microphone. Talk to your family at any time
Waterproof and dustproof
Waterproof and dustproof design, easy to deal with outdoor weather
Abnormal records can be checked at any time
24 hours on duty, audio and video videos of abnormal situations will be automatically recorded and storedThere are backups for safety, and important information is not omitted. Support memory card and cloud video storage, flexible playback, and easy checking
One-click sharing is more fun
Remotely shoot through Vstarcam’s “O-KAM” APP and upload to social networks. You can share videos or pictures on Sina Weibo or forward them to WeChat friends and Moments. Rich network functions can further expand the joy of life.
Specs
| Sorts | Type | Parameters |
| System | Operating system | Embedded Linux |
| Online visitor | Supports 4 visitors at the same time | |
| Collection | CPU/Image sensor | 1/3 inch CMOS sensor |
| Minimum illumination | 0.5 Lux(Color mode), 0.1 Lux(B&W mode) | |
| Lens/Viewing angle | [email protected]/90.9°Diagonal | |
| Night Vision | IR-CUT with auto-switching, 4pcs 850nm IR LED lights, Irradiation distance 5~10 m | |
| Video | Compression standard | H.264 main profile/Motion-JPEG/JPEG |
| Data rate | Main stream: 1296p(2304×1296)@25fps | |
| Substream：360p(640×360)@25fps | ||
| Bit rate/maximum frame rate | 128～4096kbps/25fps | |
| Image adjustment | Brightness, contrast, saturation, chroma are adjustable | |
| Audio | Input | Built-in－38dB microphone |
| Output | Built-in 8Ω1.5W speaker | |
| Sampling frequency/bit width | 8KHz/16bit | |
| Compression standard/Bit Rate | G.711/32kbps | |
| Network | Network interface | 10Mbps/100Mbps self-adaptive/RJ45 Interface |
| Network protocol | TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,RTSP,P2P etc. | |
| Wireless network | IEEE802.11b/g/n | |
| Wireless frequency | 2.4GHz | |
| Wireless security encryption | 64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption | |
| Storage | Storage functions | Support T-Flashcard(max256GB); Cloud storage; |
| Alarm | Alarm detection | Supports Motion detection; Humanoid detection; Humanoid tracking; Absences alarm; |
| Physical Indicators | Rated voltage | DC12V±5% |
| Power consumption | Rated power: 3.8 W(with IR LED lights ON)/ Max Power:5W | |
| Operating condition | Temperature: -10～50℃; Humidity: ＜90% | |
| Weight | N.W.: 335g（Note: in kind prevail） | |
| Packaging Size | 228x149x93mm (LxWxH) |
